Wireless Digital Reversing Camera System with 2 x 7'' LCD Monitor & 1 Camera
Part Number: S.143671Categories: Electrical Accessories
Part Number: S.143671
Grade: Replacement
Part Details
Wireless Digital Reversing Camera System with 2 x 7'' LCD Monitor & 1 Camera Contains: 2 x 7'' TFT-LCD Monitor, 1 x 1/3 CMOS Camera , 2 x Removable sunvisor, 2 x Adjustable support, 1 x ManualMax. no. of cameras: 1 (Max. shown on screen: 1)Max. transmitting distance: 40(M)Temperature range: -20°C to 70°CNight visionCamera viewing angle: 120°IP Rating: IP69KVolts: DC11~32V
Technical Information
| Additional camera | No |
| Audio | No |
| Auto reverse switch cable | No |
| Brand | Sparex |
| Brightness | 450 |
| Camera IP rating | IP69K |
| Certification | CE, RoHS, R&TTE |
| Colour encoding | PAL/NTSC |
| Connectivity | Digital (2.4GHz Wireless) |
| Contains | 2 x 7'' TFT-LCD Monitor, 1 x 1/3 CMOS Camera , 2 x Removable sunvisor, 2 x Adjustable support, 1 x Manual |
| Contrast | 500:1 |
| Depth mm | 70.4 |
| Features | TFT LCD Digital Wireless Monitor with wide 120° angle view and NTSC HD resolution. - Picture can be adjusted for Horizontal, Vertical, Mirror and Normal viewing. - Automatic back lighting. Full-function remote control Up to 4 monitors can be used. Monitor & Camera operates from 8 - 32V. Supports 12V or 24V. - Brightness, contrast and tint adjustment. Automatic scanning function. High response time: 25ms. - Infra-red LED function. Automatic day and night switch mode. Shockproof rating 10G |
| Fits SD card size | No |
| Frame rate FPS | PAL: 25, NTSC: 30 |
| Height mm | 75 |
| IP Rating | IP69K |
| Loop option | No |
| Maximum number of cameras | 1 |
| Maximum number of cameras shown on screen | 1 |
| Maximum number of monitors | 4 |
| Maximum transmitting distance meters | 40 |
| Mirror function | No |
| Monitor IP rating | IP54 |
| Monitor size | 218x149x82 |
| Monitor type | LCD |
| Night vision | Yes |
| Notes | TFT LCD Digital Wireless Monitor with wide 120° angle view and NTSC HD resolution. |
| Quad screen | No |
| Recording function | No |
| Related Products | 143672, 154883 |
| Resolution | 800 (RGB) x 480 |
| Split screen | No |
| Tariff Code | 8525809900 |
| Temperature Range | -20°C to 70°C |
| Touch screen | No |
| Viewing angle camera | 120° |
| Viewing angle monitor | L/R: 70/70 U/D: 50/70 |
| Volts | DC11~32V |
| Width mm | 106 |
