Water Pump Assembly (Supplied with Pulley) for Massey Ferguson 565 (500 Series)
Part Number: S.48020Categories: Engine Fuel and Filters
Part Number: S.48020
Grade: Replacement
Part Details
Water Pump Assembly (Supplied with Pulley) GroovesAlternative to S.40037
Technical Information
| Overall width (mm) | 106.9 |
| Overall height (mm) | 120 |
| Pulley Ø (mm) | 124.3 |
| Number of Hub Holes | 4 |
| Related products | 40007,40008,40047 |
| Alternative to | 40037 |
| PCD | 63.5 |
| Impeller Ø (mm) | 78 |
| Overall length (mm) | 82.5 |
| Tariff Code | 8413308090 |
| Notes | Alternative to S.40037 |
| Perkins Build List | Perkins Build List: LA, LD (Except LD14420(>236U97730), 20007, 22684 (>U86731J), 50094, 50119), LE22241, 22395, 70089, LF (Except LF21577, 21824, 22165, 22595, 22663, 22801), LG50067, 50085, 70063, 70090, 70091, 70097, 70127, LJ50079 (>U867831J) |
| Brand | Sparex |
| Pulley type | V-Style |
| Supplied with Pulley | Yes |
Manufacturer Part Numbers
| Landini |
|---|
| 10500006, 10576007, 10920009, 10920058, 12431154, 131146009, 131153501, 133478201, 136866721, 137711711, 141312551, 141313201, 141313225, 141313231, 353433X1, 3641832M91, 40576002, 40826212, 40920053, 41312323, 41312366, 41312551, 41312733, 41312756, 41313225, 41313232, 4131A013, 4131A021, 4131A029, 4131A034, U5MW0104 |
| Massey Ferguson |
| 3637411M91, 3640565M91, 3641219M91, 3641832M91, U5MW0104 |
| Perkins |
| 41312161, 41312323, 41312366, 41312489, 41312551, 41312554, 41312561, 41312564, 41312566, 41312567, 41312568, 41312733, 41312743, 41312756, 41313225, 41313232, 4131A013, 4131A021, 4131A029, U5MW0104 |
