Vacuum pump - STAR60MA - PTO driven - 540 RPM for Battioni Pagani Pomp
Part Number: S.143439Categories: Muck Spreader
Part Number: S.143439
Grade: Replacement
Part Details
Vacuum pump - STAR60MA - PTO driven - 540 RPM Rotation:Anti-clockwise rotation Lubrication:Automatic lubricationCapacity LPM: 10800Oil Tank Capacity (ltrs.): LMax. Working Pressure: 1.5 BarVacuum Max.: 0.9 Bar
Technical Information
| A mm | 286 |
| B mm | 245 |
| Brand | Battioni |
| C mm | 204 |
| Capacity LPM | 10800 |
| D mm | 80 |
| Drive Type | PTO driven |
| E mm | 735 |
| F mm | 18 |
| H mm | 540 |
| Height mm | 540 |
| I mm | 80 |
| J mm | 247 |
| K mm | 220 |
| L mm | 220 |
| Length mm | 735 |
| M mm | 440 |
| Maximum RPM | 540 |
| Maximum Working Pressure | 1.5 Bar |
| Model | STAR60MA |
| N mm | 80 |
| P mm | 326 |
| Power Absorption Max. Pressure kw | 30 |
| Power Absorption Max. Vacuum kw | 26 |
| Related Products | 101971, 59489, 72201, 79297 |
| Rotation | Anti-clockwise rotation |
| Shaft | 1 3/8 - 6 splines |
| Tariff Code | 8414102530 |
| Vacuum Max. Hg | 0.9 Bar |
| Width mm | 440 |
Models
| Battioni Pagani Pomp |
|---|
| STAR60MA |
Manufacturer Part Numbers
| Battioni Pagani Pomp |
|---|
| 9730800002 |
