Top Link Standard Duty (Cat.1/1) Ball and Ball, Min. Length: 265mm.
Part Number: S.140528Categories: PTO (shaft), Linkage
Part Number: S.140528
Grade: Replacement
Part Details
Top Link Standard Duty (Cat.1/1) Ball and Ball, Min. Length: 265mm. Tube length: 150mm,Min. Length: 265mm,Max. Length: 335mm,Thread size: M24 x 3
Technical Information
| Brand | Sparex |
| Category | 1/1 |
| Category Implement End | 1 |
| Category Tractor End | 1 |
| Implement End | Ball |
| Maximum Length ins | 133/16 |
| Maximum Length mm | 335 |
| Minimum Length ins | 10 7/16 |
| Minimum Length mm | 265 |
| Suitable for Tractors up to hp kW | 40hp (30kW) |
| Tariff Code | 8708999790 |
| Thread size | M24 x 3.00 |
| Thread type | Metric |
| Tractor End | Ball |
| Tube Length ins | 5 29/32 |
| Tube length mm | 150 |
