Top Link Heavy Duty (Cat.3/3) Ball and Q.R. Hook, Min. Length: 560mm.
Part Number: S.29591Categories: PTO (shaft), Linkage
Part Number: S.29591
Grade: Replacement
Part Details
Top Link Heavy Duty (Cat.3/3) Ball and Q.R. Hook, Min. Length: 560mm. Tube length: 360mm,Min. Length: 560mm,Max. Length: 790mm,Thread size: M36 x 3
Technical Information
| Brand | Sparex |
| Category | 3/3 |
| Category Implement End | 3 |
| Category Tractor End | 3 |
| Centre Tube | S.29321 |
| Centre Tube Size mm | 60.3 x 6.35 |
| Colour | Black |
| Duty | Heavy |
| Implement End | Q.R. Hook |
| Locking Collar | S.15553 |
| Maximum Length ins | 31 |
| Maximum Length mm | 790 |
| Minimum Length ins | 22 3/4 |
| Minimum Length mm | 560 |
| Related Products | 14636, 15553, 29321, 29327, 29330, 33004, 33010, 33017, 148196, 148197 |
| Release Harness | S.33017 |
| Replacement Implement End | S.29327 |
| Replacement Tractor End | S.29330 |
| Suitable for Tractors up to hp kW | 180hp (135kW) |
| Tariff Code | 8412212000 |
| Thread size | M36 x 3.00 |
| Thread type | Metric |
| Tractor End | Ball |
| Tube Length ins | 14 |
| Tube length mm | 360 |
