Top Link Forged Hook - Cat. 3, Thread size: M36 x 3 (RH)

Part Number: S.33055Categories: PTO (shaft), Linkage
Top Link Forged Hook - Cat. 3, Thread size: M36 x 3 (RH)
Top Link Forged Hook - Cat. 3, Thread size: M36 x 3 (RH)
Top Link Forged Hook - Cat. 3, Thread size: M36 x 3 (RH)

Part Number: S.33055

Grade: Replacement

Part Details

Top Link Forged Hook - Cat. 3, Thread size: M36 x 3 (RH) Thread length: 210mm, Length: 330mm.

Technical Information

Brand CBM
Category 3
End Radius ins 2 3/4
End Radius mm 70
Hook Ø ins 2 23/64
Hook Ø mm 60
Length ins 13
Length mm 330
LH or RH RH
Notes CBM Type
Related Products 33004, 33010, 33017, 33202, 140512, 148196, 148197
Tariff Code 8708999790
Thread length ins 8 17/64
Thread length mm 210
Thread size M36 x 3.00
Thread type Metric
To Fit Ball Cat 2 S.33004
To Fit Ball Cat 3 S.33010
