Tandem Hydraulic Pump for Case IH, Bosch

Part Number: S.34408Categories: Hydraulics
Tandem Hydraulic Pump for Case IH, Bosch
Tandem Hydraulic Pump for Case IH, Bosch

Part Number: S.34408

Grade: Replacement

Part Details

Tandem Hydraulic Pump Max. LPM: 33 | 24, Max. GPM: 8.7 | 6.3,Pump rotation: Anti-Clockwise.

Technical Information

Brand Sparex
Diagram specifications A: , - B (mm): 200.8, - C: 60, - D: 60, - E: 20, - F: 40, - G: M6, - H: 15, - I: 35, - J: M6, - K: M18 x 1.5, - L: M18 x 1.5, - M: , - N: , - O: , - P: M18 x 1.5.
Front inlet hole fixing hole size M6
Front inlet hole fixing hole spacing 40
Front inlet hole size 20
Front outlet hole fixing hole size M6
Front outlet hole fixing hole spacing 35
Front outlet hole size 15
Inner max. gallon per minute 8.7
Inner maximium litres per minute 33
Length mm 200.8
Outer max. gallons per minute 6.3
Outer maximium litres per minute 24
Pump rotation Anti-Clockwise
Pump type Tandem Pump
Rear Inlet Hole Fixing Hole Spacing M18 x 1.5
Rear Inlet Hole Size M18 x 1.5
Rear Outlet Hole Fixing Hole Size M18 x 1.5
Side hole spacing 60
Tariff Code 8413603190
Top hole spacing 60

Models

Case IH
1046 (46 Series), 1246 (46 Series), 724 (24 Series), 824 (24 Series), 946 (46 Series)

Manufacturer Part Numbers

Bosch
0510565314
Case IH
3146446R91, 3146446R93, 3146446R94
