Starter Motor - 12V, 4.2Kw, Gear Reducted (Mahle) for Fiat L85 (L Series)
Part Number: S.127875Categories: Electrical Accessories
Part Number: S.127875
Grade: Replacement
Part Details
Starter Motor - 12V, 4.2Kw, Gear Reducted (Mahle)
Technical Information
| a Angle ° | -45 |
| A mm | 146 |
| B mm | 110 |
| Bell Opening | RH |
| Brand | Mahle |
| C mm | 30 |
| D mm | 35 |
| Distance Between Teeth mm | 14.7 |
| E mm | 12.2 |
| Fitting | 3 Hole Flange - RH Opening |
| Gear Reducted | Yes |
| Height mm | 161.9 |
| Kilowatts | 4.2 |
| Length from Front Mounting Face to Rear mm | 240 |
| Length mm | 381 |
| Mounting Hole mm | 12.2 |
| Number of Flange Holes | 3 |
| Number of Teeth | 9 |
| Outer Diameter of Battery Terminal mm | 9.8 |
| Tariff Code | 8511400090 |
| Volts | 12V |
| Width mm | 222.3 |
Manufacturer Part Numbers
| AC Delco |
|---|
| DRS8980 |
| Bosch |
| 1230007, 1230010, 1230023, 1262008, 986018980, SR9979N, SR9979X |
| Case IH |
| 4739353, 500338952, 82980757, 87538219 |
| Fiat |
| 4169096, 4172113, 4669705, 4692478, 4697762, 4699705, 4702248, 4737755, 4739353, 4754854, 4775109, 4807375, 99449113 |
| Ford New Holland |
| 2000314, 2000318, 4169096, 4172113, 4669705, 4692478, 4697762, 4699705, 4702248, 4737755, 4739353, 4754854, 4807375, 500338952, 5801441814, 5801441816, 82980757, 87538219, 99449113 |
| Iskra |
| IS1262 |
| IVECO |
| 4755109, 500325145, 500338952, 504059251 |
| Lester |
| 18374 |
| Lucas |
| LRS01562 |
| Magnetimar |
| 63216831, 63522300, 63522300070, MSN2039 |
