Single Hydraulic Pump Bosch (0510 615 023, 510615023)
Part Number: S.34368Categories: Hydraulics
Part Number: S.34368
Grade: Replacement
Part Details
Single Hydraulic Pump Max. LPM: 48, Max. GPM: 12.68, Pump rotation: Clockwise.
Technical Information
| Brand | Sparex |
| Diagram specifications | A: 15, - B (mm): 102, - C: 60, - D: 60, - E: 15, - F: 35, - G: M6, - H: 20, - I: 40, - J: M6. |
| Front inlet hole fixing hole size | M6 |
| Front inlet hole fixing hole spacing | 35 |
| Front inlet hole size | 15 |
| Front outlet hole fixing hole size | M6 |
| Front outlet hole fixing hole spacing | 40 |
| Front outlet hole size | 20 |
| Inner max. gallon per minute | 12.68 |
| Inner maximium litres per minute | 48 |
| Length mm | 102 |
| Lip measurement | 15 |
| Pump rotation | Clockwise |
| Pump type | Single Pump |
| Side hole spacing | 60 |
| Tariff Code | 8413603190 |
| Top hole spacing | 60 |
Manufacturer Part Numbers
| Bosch |
|---|
| 0510 615 023, 510615023 |
