Sears Air Suspension Seat
Part Number: S.71065Categories: Tractor Cabin
Part Number: S.71065
Grade: Replacement
Part Details
Sears Air Suspension Seat FeaturesDouble depth Fabriform® comfort cushionsBackrest TiltMechanical Lumbar AdjustmentArmrests with height pitch & tilt up adjustmentOperator presence switchDocument PouchSwivel 24° - 24°Automatic height adjustment Suspension stroke +/- 65mmFore - aft side travel of 200mmFixed shock absorberHorizontal isolator fully integrated, sprung & Duo® DampedAdjustable Duo® damperVibration performance to ISO 7096Supplied with multifix mounting kit
Technical Information
| Backrest Tilt | Yes |
| Brand | Sears |
| Colour | Grey |
| Document Pouch | Yes |
| Features | Double depth Fabriform® comfort cushions - Backrest Tilt - Mechanical Lumbar Adjustment - Armrests with height pitch & tilt up adjustment - Operator presence switch - Document Pouch - Swivel 24° - 24° - Automatic height adjustment - Suspension stroke +/- 65mm - Fore - aft side travel of 200mm - Fixed shock absorber - Horizontal isolator fully integrated, sprung & Duo® Damped - Adjustable Duo® damper - Vibration performance to ISO 7096 - Supplied with multifix mounting kit |
| Height mm | 798 |
| Material | Fabric/ |
| Mechanical Lumber Adjustment | Yes |
| Model | 5545A |
| Operator Presence Switch | Yes |
| Related Products | 1542, 56843, 71106, 165381, 165384, 165388, 165390, 165392, 165394, 165398, 165401, 165402 |
| Seat Belt Fixing Points | Yes |
| Seat Type | Std. |
| Shock Absorber | Fixed |
| Slide Travel mm | 200 |
| Suspension Air | Yes |
| Suspension Mechanical | No |
| Suspension Stroke mm | +/- 65 |
| Tariff Code | 9401200000 |
| Turntable | 24° - 24° |
| Volts | 12V |
| Weight Adjustment kgs | 30 - 140 |
