S Tine 32x10x520mm for Universal VARIOUS
Part Number: S.77215Categories: Cultivation, Tillage
Part Number: S.77215
Grade: Replacement
Part Details
S Tine 32x10x520mm Overall height: 520mm, Width of spring: 220mm, Height of spring: 167mm, Height to frame: 298mm, Frame mounting hole Ø: 13.5mm, Point hole Ø: 11.5mm, Fitted with: S.78686 (6mm Point).
Technical Information
| A mm | 520 |
| B mm | 220 |
| Brand | Sparex |
| C mm | 167 |
| D mm | 298 |
| F Ø mm | 13.5 |
| Fitted with | S.78686 (6mm Point) |
| Frame mounting hole Ø mm | 13.5 |
| G Ø mm | 11.5 |
| Height of spring mm | 167 |
| Height to frame mm | 298 |
| Overall height mm | 520 |
| Point hole Ø mm | 11.5 |
| Related Products | 22328, 77118, 77119, 77127, 78686, 79397 |
| Section mm | 32x10 |
| Tariff Code | 8433900000 |
| Thickness mm | 10 |
| Width of spring mm | 220 |
