PTO Shaft - (Lz) Length: 1010mm, 1 3/8'' x 6 Spline Q.R. to 1 3/8'' x 6 Spline Q.R.
Part Number: S.162393Categories: PTO (shaft), Linkage
Part Number: S.162393
Grade: Replacement
Part Details
PTO Shaft - (Lz) Length: 1010mm, 1 3/8'' x 6 Spline Q.R. to 1 3/8'' x 6 Spline Q.R. HP Rating @ 540RPM: 21HP, Series: AB2/A2.
Technical Information
| Brand | Sparex |
| HP Rating @ 540RPM | 21 |
| HP Rating Range @ 540RPM | up to 54 |
| Implement End | 1 3/8'' x 6 Spline Q.R. |
| Italian Series | AB2/A2 |
| Kilowatt Power Rating @ 540RPM | 15 |
| Lz Length mm | 1010 |
| PTO Series | AB2/A2 |
| Related Products | 2447, 24812, 24813, 59605, 59635, 6038, 6080, 6081, 166692, 166693 |
| Tariff Code | 8483908990 |
| Torque Newton Metres | 270 |
| Torque Range Nm | 210-334Nm |
| Total Closed Length mm | 1208 |
| Tractor End | 1 3/8'' x 6 Spline Q.R. |
| Tube Profile | Triangle |
| Tube Ref | 12504/12505 |
| Universal Joint Dimensions | 23.8 x 61.2mm |
