Piston & Ring Set for Ford New Holland 5010S
Part Number: S.62022Categories: Engine Fuel and Filters
Part Number: S.62022
Grade: Replacement
Part Details
Piston & Ring Set Piston Length = 108.55mm. Chamber Depth = 22.95mm. Chamber Ø49.21mm. Pin Ø38mm. Compression Height = 65.26mm. To Fit Bore Ø99.89mm. No. of Rings = 3.
Technical Information
| Number of Rings | 3 |
| Pin Ø (mm) | 38 |
| Related products | 62022,62028,62034,62080,62083,62085,62102,62104,62105,62106,62109 |
| Tariff Code | 8409910090 |
| Bore Ø (mm) | 99.92 |
| Brand | Sparex |
| Ring Type | Top Ring: P1 - Parallel Faced Plain (2.50mm) - 2nd Ring: N1 - Napier, Externally Stepped Bottom With Single Hook (2.50mm) - 3rd Ring: CBEH - Chrome Plated Bevelled Edge with Helical Coil Spring (5.50mm) |
Manufacturer Part Numbers
| Case IH |
|---|
| 1940174 |
| Fiat |
| 1930241, 4770645, 82982151 |
| Ford New Holland |
| 01930241, 1930241, 1940174, 82982151 |
| SIP |
| 153171419, 153932908 |
