Parker JIC 37° Hose Insert 1/4'' x 7/16'' x 20'' Female 90° Swept Swivel (Short) PARKER HANNIFIN (13W48-4-4)
Part Number: S.3230704Categories: Hydraulics
Part Number: S.3230704
Grade: Replacement
Part Details
Parker JIC 37° Hose Insert 1/4'' x 7/16'' x 20'' Female 90° Swept Swivel (Short) A (mm) 48B (mm) 24E (mm) 21H (mm) 17
Technical Information
| A mm | 48 |
| B mm | 24 |
| Brand | Parker |
| Cone angle | 37° |
| E mm | 21 |
| Fitting | 1 Piece Fitting |
| H mm | 17 |
| Hose inner Ø ins | 1/4 |
| Hose inner Ø mm | 6.3 |
| Male Female | Female |
| Nominal I.D. | DN06 |
| Position | 90° Swept Swivel (Short) |
| Reference | 13W48-4-4 |
| Series | 48 |
| Tariff Code | 7307199000 |
| Thread size | 7/16'' x 20 |
| Thread type | JIC |
| Type | JIC 90° Swept Female |
Manufacturer Part Numbers
| PARKER HANNIFIN |
|---|
| 13W48-4-4 |
