Orbital Hydraulic Motor Danfoss (OMH200)
Part Number: S.137218Categories: Hydraulics
Part Number: S.137218
Grade: Replacement
Part Details
Orbital Hydraulic Motor Motor Type: MOMHDisplacement cm°³: 203Flow Rate: 75L/min
Technical Information
| Brand | Trale |
| Displacement cm³ | 203 |
| Drain Port Thread | 1/4" |
| Flange Type | SAE A4 Oval Flange - 4 Hole |
| Hydraulic Motor Type | MOMH |
| L mm | 168 |
| L1 mm | 28 |
| Main Port Thread Size | 1/2'' |
| Maximum Continuous KW Power | 13.8 |
| Maximum Continuous Torque Nm | 42.5 |
| Maximum Continuous Working Pressure Bar | 160 |
| Maximum Flow Rate LPM | 75 |
| Maximum Peak Torque Nm | 590 |
| Maximum Peak Working Pressure Bar | 220 |
| Maximum RPM | 370 |
| Model | OMH200 |
| Related Products | 153126 |
| Seal Kit and Repair Kits | S.153126 |
| Shaft Ø mm | 32 |
| Shaft type | Straight / Parallel |
| Tariff Code | 8708999790 |
| Thread type | BSP |
Manufacturer Part Numbers
| Danfoss |
|---|
| OMH200 |
