Orbital Hydraulic Motor Danfoss (11186712, 1510317, 1510617, OMP315, OMP3151510317)
Part Number: S.137145Categories: Hydraulics
Part Number: S.137145
Grade: Replacement
Part Details
Orbital Hydraulic Motor Motor Type: OMPDisplacement cm°³: 306.1Flow Rate: 60L/min
Technical Information
| Brand | Danfoss |
| Displacement cm³ | 306.1 |
| Drain Port Thread | 1/4" |
| Flange Type | SAE Flange - 2 Hole |
| Hydraulic Motor Type | OMP |
| L mm | 166.5 |
| L1 mm | 40.9 |
| Main Port Thread Size | 1/2" |
| Maximum Continuous KW Power | 5 |
| Maximum Continuous Torque Nm | 300 |
| Maximum Continuous Working Pressure Bar | 75 |
| Maximum Flow Rate LPM | 60 |
| Maximum Peak Torque Nm | 600 |
| Maximum Peak Working Pressure Bar | 160 |
| Maximum RPM | 195 |
| Model | OMP315 |
| Reference | 11186712 |
| Related Products | 137136, 137163 |
| Seal Kit and Repair Kits | S.137136 |
| Shaft Ø mm | 25 |
| Shaft type | Straight / Parallel |
| Tariff Code | 8708999790 |
| Thread type | BSP |
Manufacturer Part Numbers
| Danfoss |
|---|
| 11186712, 1510317, 1510617, OMP315, OMP3151510317 |
