MachineCam HD Wireless Camera System

Part Number: S.164680Categories: Electrical Accessories
MachineCam HD Wireless Camera System
MachineCam HD Wireless Camera System
MachineCam HD Wireless Camera System
MachineCam HD Wireless Camera System
MachineCam HD Wireless Camera System
MachineCam HD Wireless Camera System
MachineCam HD Wireless Camera System

Part Number: S.164680

Grade: Replacement

Part Details

MachineCam HD Wireless Camera System MachineCam HD is a wireless camera system with very high image quality (HD) and long range (300 m). Developed to perform without interference in the toughest of conditions. Often used for harvesting, baling, reversing, etc. For safer and more efficient work.The camera can be used together with the original Luda Farm Powerbank (S.129833), a solid rechargeable battery with a very strong magnet. This allows you to move and place the camera where it captures the best video for you on your vehicle or machine.The monitor on MachineCam HD is improved with higher resolution, greater clarity + 25% (for sunny days) and the new image format, true 16: 9, that shows the image exactly as it looks in reality.The camera system delivers high definition video in all light conditions. In the dark, the camera's high-powered IR-system lights up approx. 15 meters in front of the camera.The MachineCam HD screen automatically connects up to 4 cameras and can automatically switch to the reverse-camera when reversing. With the split-screen feature, you can view 2 cameras simultaneously. If you want, you can also record your work. With MachineCam HD, you can use an SD card to easily record and document what you see on the monitor.Robust construction and built to last.Contains: 1 x 7 TFT-LCD Monitor 800 (RGB) x 720 Resolution (S.164681)1 x 1/3 CMOS Camera & Power Cable (Additional Camera Kit S.164681)1 x Removable sunvisor(S.164687)1 x Dual Suction Bracket (S.128975)1 x 3m 12V Cigarette plug for monitor (S.164684)1 x 3m Power cable for monitor (S.164685)1 x Manual

Technical Information

Additional camera S.164681
Audio Yes
Audio output 1.5W
Auto reverse switch cable Yes
Brand Luda
Brightness 500 cd/m²
Camera IP rating IP69K
CE Approved Yes
Colour encoding PAL/NTSC
Connection Type Wireless
Connectivity Digital (2.4GHz Wireless)
Contains 1 x 7 TFT-LCD Monitor 800 (RGB) x 720 Resolution (S.164681) - 1 x 1/3 CMOS Camera & Power Cable (Additional Camera Kit S.164681) - 1 x Removable sunvisor(S.164687) - 1 x Dual Suction Bracket (S.128975) - 1 x 3m 12V Cigarette plug for monitor (S.164684) - 1 x 3m Power cable for monitor (S.164685) - 1 x Manual
Contrast 800:1
Fits SD card size 128GB
Frame rate FPS PAL: 25, NTSC: 30
IP Rating IP69K
Loop option Yes
Maximum number of cameras 4
Maximum number of cameras shown on screen 4
Maximum transmitting distance meters 300m
Mirror function Yes
Monitor size 7''
Monitor type LCD
Night vision Yes
Notes MachineCam HD is a wireless camera system with very high image quality (HD) and long range (300 m). Developed to perform without interference in the toughest of conditions. Often used for harvesting, baling, reversing, etc. For safer and more efficient work. - The camera can be used together with the original Luda Farm Powerbank (S.129833), a solid rechargeable battery with a very strong magnet. This allows you to move and place the camera where it captures the best video for you on your vehicle or machine. - The monitor on MachineCam HD is improved with higher resolution, greater clarity + 25% (for sunny days) and the new image format, true 16: 9, that shows the image exactly as it looks in reality. - The camera system delivers high definition video in all light conditions. In the dark, the camera's high-powered IR-system lights up approx. 15 meters in front of the camera. - The MachineCam HD screen automatically connects up to 4 cameras and can automatically switch to the reverse-camera when reversing. With the split-screen feature, you can view 2 cameras simultaneously. If you want, you can also record your work. With MachineCam HD, you can use an SD card to easily record and document what you see on the monitor. - Robust construction and built to last.
Quad screen No
Recording function Yes
Related Products 109865, 109866, 128975, 129833, 164681, 164682, 164683, 164684, 164685, 164686, 164687
Resolution 1024 x 3 (RGB) x 600
RoHS Approved Yes
Split screen Yes
Supplied with 1 x 7 TFT-LCD Monitor 800 (RGB) x 720 Resolution (S.164682) - 1 x 1/3 CMOS Camera (Additional camera S.164681) - 1 x Removable sunvisor (S.164687) - 1 x Dual Suction Bracket (S.128975) - 1 x 3m 12V Cigarette plug for monitor (S.164684) - 1 x 3m Power cable for monitor (S.164685) - 1 x Manual
Tariff Code 8528724000
Temperature Range -20°C to 70°C
Touch screen No
Viewing angle camera 110°
Viewing angle monitor U: 70 / D: 75, R/L: 75
Volts 10-32V
