Loader Tine - Cranked 810mm, Thread size: M22 x 1.5 (Star)
Part Number: S.72557Categories: Loader Tines
Part Number: S.72557
Grade: Replacement
Part Details
Loader Tine - Cranked 810mm, Thread size: M22 x 1.5 (Star) Fitting: Conus 1 Max. Tine Ø36mm
Technical Information
| A mm | 810 |
| B mm | 131 |
| Brand | SHW |
| Bush HD | S.22829 |
| Bush STD | S.21527 |
| Colour | Red |
| Conus Reference | K001 |
| Fitting | Conus 1 |
| Length Tine ins | 32 |
| Length Tine mm | 810 |
| Maximum Tine Ø mm | 36 |
| Maximum Torque Nm | 500 |
| Nut | S.77028 |
| Nut Included | Yes |
| Profile | Star |
| Related Products | 21527, 22829, 77028 |
| Tariff Code | 8431492000 |
| Thread size | M22 x 1.50 |
| Thread type | Metric |
| Type | Cranked |
