LED Work Light, Interference: Class 5, 4200 Lumens Raw, 10-30V for Steyr 4110 PROFI - CVT
Part Number: S.163876Categories: Electrical Accessories
Part Number: S.163876
Grade: Replacement
Part Details
LED Work Light, Interference: Class 5, 4200 Lumens Raw, 10-30V ECE Rating: Reg10 - E4 10R06/00*4552*00CE Approved: YesIP Rating: IP6K9KConnection Type: ITT Connector
Technical Information
| Working Temperature °C | -40°C |
| Power Consumption @ 24V: | 1.13Amps |
| Volts | 10-30V |
| Overall height (mm) | 104 |
| Overall length (mm) | 152 |
| Beam Angle | 160° |
| Related products | 163878,163912 |
| Power Consumption @ 12V: | 2.25Amps |
| Effective Lumens | 2310 |
| Lux Value | 2413.8cd |
| Number of LEDs: | 30 LEDs |
| Watts | 30W |
| Cable length (mm) | 400 |
| Lumens Raw | 4200 |
| Tariff Code | 8539100090 |
| Overall width (mm) | 99 |
| Housing Material | Aluminium |
| Fixing: | Bracket |
| Interference EMC EMI CISPR 25 | Class 5 |
| Lens Colour | Clear |
| Beam Type | Flood Beam |
| IP Rating | IP6K9K |
| Connection Type | ITT Connector |
| Light source | LED |
| SAE Approved | No |
| Lens Material | Plastic Safety Glass |
| Shape | Rectangular |
| ECE Rating | Reg10 - E4 10R06/00*4552*00 |
| Brand | Sparex |
| CE Approved | Yes |
| RoHS Approved | Yes |
| With Noise Suppression | Yes |
