LED Work Light, Interference: Class 3, 4800 Lumens, 10-30V () for John Deere 6420 (6020 Series)

Part Number: S.149213Categories: Electrical Accessories
LED Work Light, Interference: Class 3, 4800 Lumens, 10-30V () for John Deere 6420 (6020 Series)
LED Work Light, Interference: Class 3, 4800 Lumens, 10-30V () for John Deere 6420 (6020 Series)
LED Work Light, Interference: Class 3, 4800 Lumens, 10-30V () for John Deere 6420 (6020 Series)
LED Work Light, Interference: Class 3, 4800 Lumens, 10-30V () for John Deere 6420 (6020 Series)

Part Number: S.149213

Grade: Replacement

Part Details

LED Work Light, Interference: Class 3, 4800 Lumens, 10-30V () ECE Rating: Reg 10CE Approved: YesIP Rating: IP69KConnection Type: None

Technical Information

Beam Angle 160°
Beam Type Flood Beam
Brand Sparex
Cable length mm 100
CE Approved Yes
Connection Type None
ECE Rating Reg 10
Fixing 1 Bolt
Housing Material Aluminium
Interference EMC EMI CISPR 25 Class 3
IP Rating IP69K
Lens Colour Clear
Lens Material Plastic Safety Glass
Light source LED
Lumens Effective 3500
Lumens Raw 4800
Lux Value 5678
Number of LEDs 21 LEDs
Overall height mm 154.2
Overall length mm 112.2
Overall width mm 68.9
Power Consumption @ 12V 2.25Amps
Power Consumption @ 24V 1.12Amps
Related Products 143231, 130542
RoHS Approved Yes
SAE Approved No
Shape Oval
Tariff Code 8539500000
Volts 10-30V
Watts 27W
With Noise Suppression Yes
Working Temperature Degrees Centregrade -45°C to 60°C
