LED Work Light, Interference: Class 1, 900 Lumens, 10-30V ()

Part Number: S.29319Categories: Electrical Accessories
LED Work Light, Interference: Class 1, 900 Lumens, 10-30V ()
LED Work Light, Interference: Class 1, 900 Lumens, 10-30V ()
LED Work Light, Interference: Class 1, 900 Lumens, 10-30V ()
LED Work Light, Interference: Class 1, 900 Lumens, 10-30V ()
LED Work Light, Interference: Class 1, 900 Lumens, 10-30V ()
LED Work Light, Interference: Class 1, 900 Lumens, 10-30V ()

Part Number: S.29319

Grade: Replacement

Part Details

LED Work Light, Interference: Class 1, 900 Lumens, 10-30V () ECE Rating: Reg 10CE Approved: YesIP Rating: IP6K9KConnection Type: For Male or Female Insulated Terminal

Technical Information

Ø mm 84
Beam Angle 60°
Beam Type Flood Beam
Brand Sparex
Cable length mm 1000
CE Approved Yes
Connection Type For Male or Female Insulated Terminal
ECE Rating Reg 10
Fixing Bracket
Housing Material Aluminium
Interference EMC EMI CISPR 25 Class 1
IP Rating IP6K9K
Lens Colour Clear
Lens Material Plastic Safety Glass
Light source LED
Lumens Effective 640
Lumens Raw 900
Lux Value 2460
Notes Dimensions without bracket
Number of LEDs 4 LEDs
On Off Switch No
Overall height mm 111
Overall length mm 84
Overall width mm 65
Power Consumption @ 12V 0.92Amps
Power Consumption @ 24V 0.46Amps
Related Products 112533, 115244, 118931, 119256, 119258
RoHS Approved Yes
SAE Approved No
Shape Round
Tariff Code 8539213000
Volts 10-30V
Watts 12W
With Noise Suppression Yes
Working Temperature Degrees Centregrade -40°C to 50°C
