LED Triangle Warning Light, Interference: Class 3, 12-24V
Part Number: S.114412Categories: Electrical Accessories
Part Number: S.114412
Grade: Replacement
Part Details
LED Triangle Warning Light, Interference: Class 3, 12-24V ECE Rating: Reg 10CE Approved: YesIP Rating: IP44Function: Flashing
Technical Information
| Brand | Sparex |
| Cable length mm | 4500 |
| CE Approved | Yes |
| Connection Type | None |
| ECE Rating | Reg 10 |
| Fixing | Bolt on |
| Function | Flashing |
| Housing Material | Metal |
| Interference EMC EMI CISPR 25 | Class 3 |
| IP Rating | IP44 |
| Lens Colour | Amber |
| Lens Material | Plastic Safety Glass |
| Light source | LED |
| Lumens Effective | 1125 |
| Lumens Raw | 2250 |
| Lux Value | 108 - 216 |
| Number of LEDs | 72 LEDs |
| On Off Switch | No |
| Overall height mm | 500 |
| Overall length mm | 40 |
| Overall width mm | 500 |
| Power Consumption @ 12V | 0.8Amps |
| Power Consumption @ 24V | 0.4Amps |
| RoHS Approved | Yes |
| SAE Approved | No |
| Shape | Triangular |
| Tariff Code | 8512200090 |
| Volts | 12-24V |
| Watts | 1.2W |
| With Noise Suppression | Yes |
| Working Temperature Degrees Centregrade | -20°C to 60°C |
