LED Rotating Beacon (Amber), Interference: Class 3, Flexible Pin, 12/24V
Part Number: S.163864Categories: Electrical Accessories
Part Number: S.163864
Grade: Replacement
Part Details
LED Rotating Beacon (Amber), Interference: Class 3, Flexible Pin, 12/24V ECE Rating: Reg 10, Reg 65CE Approved: YesIP Rating: IP65Profile: Ultra-CompactFunction: Rotating
Technical Information
| Ø mm | 108 |
| Brand | Sparex |
| CE Approved | Yes |
| ECE Rating | Reg 10, Reg 65 |
| Fixing | Flexible Pin |
| Function | Rotating |
| Housing Material | Polycarbonate |
| Interference EMC EMI CISPR 25 | Class 3 |
| IP Rating | IP65 |
| Lens Colour | Amber |
| Lens Material | Polycarbonate |
| Light source | LED |
| Number of LEDs | 8 LEDs |
| Overall height mm | 150 |
| Overall length mm | 108 |
| Overall width mm | 108 |
| Power Consumption @ 12V | 1.25Amps |
| Power Consumption @ 24V | 0.6Amps |
| Profile | Ultra-Compact |
| Related Products | 164765 |
| RoHS Approved | Yes |
| SAE Approved | No |
| Shape | Round |
| Tariff Code | 8512200000 |
| Volts | 12/24V |
| Watts | 8W |
| With Noise Suppression | Yes |
| Working Temperature Degrees Centregrade | -30°C to 50°C |
