LED Head Light Kit, Interference: Class 3, RH & LH (LH Dip), 1320 Lumens, 10-30V for Renault 133-54 (52-54 Series)
Part Number: S.163620Categories: Electrical Accessories
Part Number: S.163620
Grade: Replacement
Part Details
LED Head Light Kit, Interference: Class 3, RH & LH (LH Dip), 1320 Lumens, 10-30V ECE Rating: Reg112 - E24 112R01/08*0462*00, Reg10 - E4 10R05/01*4540*00CE Approved: YesIP Rating: IP6K9KConnection Type: H4 Connector
Technical Information
| Beam Angle | Low Beam 20° / High Beam 24° |
| Brand | Sparex |
| Cable length mm | 150 |
| CE Approved | Yes |
| Connection Type | H4 Connector |
| Dip | LH Dip |
| ECE Rating | Reg112 - E24 112R01/08*0462*00, Reg10 - E4 10R05/01*4540*00 |
| Fixing | Tri-leg Bracket |
| Function | 3 Function |
| Housing Material | Aluminium |
| Interference EMC EMI CISPR 25 | Class 3 |
| IP Rating | IP6K9K |
| Lens Colour | Clear |
| Lens Material | Plastic Safety Glass |
| Light source | LED |
| Lumens Effective | 490 - 995 |
| Lumens Raw | 1320 |
| Lux Value | Low Beam 20000cd |
| Number of LEDs | 2 LEDs |
| Overall height mm | 106.5 |
| Overall length mm | 166 |
| Overall width mm | 77 |
| Power Consumption @ 12V | Low Beam 1.04Amps |
| Related Products | 130541, 152147, 151854, 163905 |
| RH or LH Fitment | RH & LH |
| RoHS Approved | Yes |
| SAE Approved | No |
| Shape | Rectangular |
| Tariff Code | 8539500000 |
| Volts | 10-30V |
| Watts | Low Beam 12.5W |
| With Noise Suppression | Yes |
| Working Temperature Degrees Centregrade | -40°C to 50°C |
