LED Head Light, Interference: Class 3, RH (LH Dip), 1200 - 1290 Lumens Raw, 10-30V for JCB FASTRAC 2115
Part Number: S.143662Categories: Electrical Accessories
Part Number: S.143662
Grade: Replacement
Part Details
LED Head Light, Interference: Class 3, RH (LH Dip), 1200 - 1290 Lumens Raw, 10-30V ECE Rating: Reg112 - E4 112R01/08*26844*00, Reg7 - E4 7R02/27*26844*00, Reg6 - E4 6R01/28*26844*00CE Approved: YesIP Rating: IP65Connection Type: DT Connector (Six Pin)
Technical Information
| Beam Angle | Low Beam 65° / High Beam 30° / Pilot Light 45° / Indicator 45-80° |
| Brand | Sparex |
| Cable length mm | 250 |
| CE Approved | Yes |
| Connection Type | DT Connector (Six Pin) |
| Dip | LH Dip |
| ECE Rating | Reg112 - E4 112R01/08*26844*00, Reg7 - E4 7R02/27*26844*00, Reg6 - E4 6R01/28*26844*00 |
| Fixing | 1 Bolt |
| Function | 4, High / Low Beam / Pilot Light / Indicator |
| Housing Material | Various Plastic Compounds |
| Interference EMC EMI CISPR 25 | Class 3 |
| IP Rating | IP65 |
| Lens Colour | Clear |
| Lens Material | Plastic Safety Glass |
| Light source | LED |
| Lumens Effective | 480 - 615 |
| Lumens Raw | 1200 - 1290 |
| Lux Value | 67300 - 26800 |
| Number of LEDs | 2 LEDs |
| Overall height mm | 161 |
| Overall length mm | 237 |
| Overall width mm | 109 |
| Power Consumption @ 12V | Low Beam 1.25Amps |
| Power Consumption @ 24V | Low Beam 0.625Amps |
| Related Products | 143232 |
| RH or LH Fitment | RH |
| RoHS Approved | Yes |
| SAE Approved | Yes |
| Shape | Rectangular |
| Tariff Code | 8539500000 |
| Volts | 10-30V |
| Watts | Low Beam 15W |
| With Noise Suppression | Yes |
| Working Temperature Degrees Centregrade | -40°C to 60°C |
