LED Beacon Kit, Interference: Class 3, Flexible Pin, 12-24V for Steyr 6140 PROFI - CLASSIC
Part Number: S.161505Categories: Electrical Accessories
Part Number: S.161505
Grade: Replacement
Part Details
LED Beacon Kit, Interference: Class 3, Flexible Pin, 12-24V Contains: S.3522 x 1S.5053 x 1S.12826 x 1S.51736 x 1S.113213 x 1S.153107 x 1S.153110 x 1S.156662 x 1S.11299 x 1S.11563 x 1S.12408 x 1S.54832 x 2S.54833 x 2S.5756 x 1
Technical Information
| Ø mm | 128 |
| Brand | Sparex |
| Cable length mm | 1000 |
| CE Approved | Yes |
| Connection Type | None |
| Contains | S.3522 x 1 - S.5053 x 1 - S.12826 x 1 - S.51736 x 1 - S.113213 x 1 - S.153107 x 1 - S.153110 x 1 - S.156662 x 1 - S.11299 x 1 - S.11563 x 1 - S.12408 x 1 - S.54832 x 2 - S.54833 x 2 - S.5756 x 1 |
| ECE Rating | Reg 65, Reg 20 |
| Fixing | Flexible Pin |
| Function | Single Flash, Double Flash, Rotating |
| Housing Material | Rubber |
| Interference EMC EMI CISPR 25 | Class 3 |
| IP Rating | IP65 |
| Lens Colour | Amber |
| Lens Material | Plastic Safety Glass |
| Light source | LED |
| Lumens Effective | 1200 |
| Lumens Raw | 2400 |
| Lux Value | 480 |
| Number of LEDs | 12 LEDs |
| Overall height mm | 210 |
| Overall length mm | 128 |
| Overall width mm | 128 |
| Power Consumption @ 12V | 1.75Amps |
| Power Consumption @ 24V | 1.79Amps |
| Profile | Low |
| Related Products | 12826, 5053, 51736, 113213, 150443, 153110 |
| RoHS Approved | Yes |
| SAE Approved | No |
| Shape | Round |
| Tariff Code | 8512909000 |
| Volts | 12-24V |
| Watts | 21-43W |
| With Noise Suppression | Yes |
| Working Temperature Degrees Centregrade | -30°C to 50°C |
Manufacturer Part Numbers
| Case IH |
|---|
| 710762034 |
| Ford New Holland |
| 710762034 |
| Steyr |
| 710762034 |
