LED Beacon (Amber), Interference: Class 3, Flexible Pin, 12-24V
Part Number: S.113199Categories: Electrical Accessories
Part Number: S.113199
Grade: Replacement
Part Details
LED Beacon (Amber), Interference: Class 3, Flexible Pin, 12-24V ECE Rating: Reg 10CE Approved: YesIP Rating: IP55Profile: StandardFunction: 3 functions: rotating, double flashes, six flashes
Technical Information
| Ø mm | 128 |
| Brand | Sparex |
| CE Approved | Yes |
| Connection Type | None |
| ECE Rating | Reg 10 |
| Fixing | Flexible Pin |
| Function | 3 functions: rotating, double flashes, six flashes |
| Housing Material | Rubber |
| Interference EMC EMI CISPR 25 | Class 3 |
| IP Rating | IP55 |
| ISO Rating | ISO 9001 |
| Lens Colour | Amber |
| Lens Material | Plastic Safety Glass |
| Light source | LED |
| Lumens Effective | 600 |
| Lumens Raw | 1200 |
| Lux Value | 240 |
| Number of LEDs | 40 LEDs |
| Overall height mm | 240 |
| Overall length mm | 128 |
| Overall width mm | 128 |
| Power Consumption @ 12V | 1.25Amps |
| Power Consumption @ 24V | 1.25Amps |
| Profile | Standard |
| Related Products | 10881, 10882, 14426, 14807, 18308, 20618, 4708, 51736, 150447 |
| RoHS Approved | Yes |
| SAE Approved | No |
| Shape | Round |
| Speed | Rotating: 120+/-4 rpm, Double Flash: 346+/-4 rpm, Six Flash: 428+/-4 rpm |
| Tariff Code | 8512200030 |
| Volts | 12-24V |
| Watts | 15-30W |
| With Noise Suppression | Yes |
| Working Temperature Degrees Centregrade | -30°C to 50°C |
