Hydraulic Top Link (Cat.3/3) Knuckle and Q.R CBM Hook, Cylinder Bore: 90mm, Min. Length : 690mm. for Case IH, Fendt, Ford New Holland, Steyr

Part Number: S.399731Categories: PTO (shaft), Linkage
Hydraulic Top Link (Cat.3/3) Knuckle and Q.R CBM Hook, Cylinder Bore: 90mm, Min. Length : 690mm. for Case IH, Fendt, Ford New Holland, Steyr
Hydraulic Top Link (Cat.3/3) Knuckle and Q.R CBM Hook, Cylinder Bore: 90mm, Min. Length : 690mm. for Case IH, Fendt, Ford New Holland, Steyr
Hydraulic Top Link (Cat.3/3) Knuckle and Q.R CBM Hook, Cylinder Bore: 90mm, Min. Length : 690mm. for Case IH, Fendt, Ford New Holland, Steyr
Hydraulic Top Link (Cat.3/3) Knuckle and Q.R CBM Hook, Cylinder Bore: 90mm, Min. Length : 690mm. for Case IH, Fendt, Ford New Holland, Steyr
Hydraulic Top Link (Cat.3/3) Knuckle and Q.R CBM Hook, Cylinder Bore: 90mm, Min. Length : 690mm. for Case IH, Fendt, Ford New Holland, Steyr
Hydraulic Top Link (Cat.3/3) Knuckle and Q.R CBM Hook, Cylinder Bore: 90mm, Min. Length : 690mm. for Case IH, Fendt, Ford New Holland, Steyr
Hydraulic Top Link (Cat.3/3) Knuckle and Q.R CBM Hook, Cylinder Bore: 90mm, Min. Length : 690mm. for Case IH, Fendt, Ford New Holland, Steyr
Hydraulic Top Link (Cat.3/3) Knuckle and Q.R CBM Hook, Cylinder Bore: 90mm, Min. Length : 690mm. for Case IH, Fendt, Ford New Holland, Steyr

Part Number: S.399731

Grade: Replacement

Part Details

Hydraulic Top Link (Cat.3/3) Knuckle and Q.R CBM Hook, Cylinder Bore: 90mm, Min. Length : 690mm. Min. Length : 690mm, Max. Length : 956mm, Supplied with : Hose set, chain & ball, marker label with knuckle & pin.

Technical Information

A mm 152
Brand Sparex
Category 3/3
Category Implement End 3
Category Tractor End 3
Check Valve Position Top
Cylinder Bore mm 90
Implement End Q.R CBM Hook
Lift kgs @180 bar 8770
Maximum Length mm 956
Minimum Length mm 690
Related Products 10288, 10292, 32257, 33004, 33010, 33017, 33137, 33144, 33158, 33202, 39965, 39966, 39967, 39968, 148196, 148197
Rod Ø mm 45
Suitable for Tractors up to hp kW 200hp (147kW)
Supplied with Hose set, chain & ball, marker label with knuckle & pin
Tariff Code 8412212000
Thrust kgs @180 bar 11700
Tractor End Knuckle
Tractor End Fixing S.10288

Models

Case IH
MXM175 (MXM Series), MXM190 (MXM Series), Puma 170 (Puma Series), PUMA 175, Puma 180 (Puma Series), PUMA 185 - CVT, PUMA 185 - CVX, Puma 185 (Puma Series), Puma 195 (Puma Series), PUMA 200 - CVT, PUMA 200 - CVX, Puma 200 (Puma Series), Puma 210 (Puma Series), Puma 215 (Puma Series), PUMA 220, PUMA 220 - CVT, PUMA 220 - CVX, PUMA 240 - CVT, PUMA 240 - CVX
Fendt
712 VARIO (712), 714 Vario (Favorit 700 Series), 716 Vario (Favorit 700 Series), 718 Vario (Favorit 700 Series), 720 VARIO SCR (735), 722 VARIO SCR (736)
Ford New Holland
T7.220 (T7 Series), T7.225, T7.230, T7.235 (T7 Series), T7.245, T7.250 (T7 Series), T7.260 (T7 Series), T7.270 (T7 Series), T7.290, T7.315, T7030 (T7000 Series), T7040 (T7000 Series), T7050 (T7000 Series), T7060 (T7000 Series), T7070 (T7000 Series), T7510, T7520, T7530, T7540, T7550
Steyr
CVT 6145, CVT 6160, CVT 6170, CVT 6185, CVT 6205, CVT 6215, CVT 6230

Manufacturer Part Numbers

Fendt
G716870050022, G737870051010
Ford New Holland
87358974, 87707441
