Hydraulic Top Link (Cat.1/2) Ball and Q.R CBM Hook, Cylinder Bore: 63mm, Min. Length : 430mm. for Ford New Holland
Part Number: S.331000Categories: PTO (shaft), Linkage
Part Number: S.331000
Grade: Replacement
Part Details
Hydraulic Top Link (Cat.1/2) Ball and Q.R CBM Hook, Cylinder Bore: 63mm, Min. Length : 430mm. Min. Length : 430mm, Max. Length : 590mm, Supplied with : Hose set, chain & ball, marker label.
Technical Information
| A mm | 100 |
| Brand | Sparex |
| Category | 1/2 |
| Category Implement End | 2 |
| Category Tractor End | 1 |
| Check Valve Position | Top |
| Cylinder Bore mm | 63 |
| Implement End | Q.R CBM Hook |
| Lift kgs @180 bar | 3960 |
| Maximum Length mm | 590 |
| Minimum Length mm | 430 |
| Related Products | 32253, 33008, 33137, 33144, 33158, 33201, 39965, 39966, 39967, 39968, 148199 |
| Rod Ø mm | 35 |
| Suitable for Tractors up to hp kW | 100hp (75kW) |
| Supplied with | Hose set, chain & ball, marker label |
| Tariff Code | 8412212000 |
| Thrust kgs @180 bar | 5730 |
| Tractor End | Ball |
Models
| Ford New Holland |
|---|
| BOOMER 3040, BOOMER 3045, BOOMER 3050 |
