for Massey Ferguson
Part Number: S.163906Categories: Electrical Accessories
Part Number: S.163906
Grade: Replacement
Part Details
Technical Information
| Beam Angle | 140° |
| Beam Type | Flood Beam |
| Brand | Sparex |
| Cable length mm | 400 |
| CE Approved | Yes |
| Connection Type | 2 pcs. DJ70215-6.3-11 Connector |
| ECE Rating | Reg10 - E4 10R05/01*4539*00 |
| Fixing | Bracket |
| Housing Material | Aluminium |
| Interference EMC EMI CISPR 25 | Class 5 |
| IP Rating | IP6K9K |
| Lens Colour | Clear |
| Lens Material | Plastic Safety Glass |
| Light source | LED |
| Lumens Effective | 2400 |
| Lumens Raw | 4500 |
| Lux Value | 8275cd |
| Number of LEDs | 15 LEDs |
| Overall height mm | 113 |
| Overall length mm | 161 |
| Overall width mm | 77 |
| Power Consumption @ 12V | 3.3Amps |
| Power Consumption @ 24V | 1.67Amps |
| Related Products | 151852, 151850, 163618, 163905 |
| RoHS Approved | Yes |
| SAE Approved | No |
| Shape | Oval |
| Tariff Code | 8539100090 |
| Volts | 10-30V |
| Watts | 45W |
| With Noise Suppression | Yes |
| Working Temperature Degrees Centregrade | -40°C |
Models
| Massey Ferguson |
|---|
| 5410, 5420 (5400 Series), 5425 (5400 Series), 5430 (5400 Series), 5435 (5400 Series), 5435 (5400 Series), 5440 (5400 Series), 5445 (5400 Series), 5450 (5400 Series), 5455 (5400 Series), 5460 (5400 Series), 5465 (5400 Series), 5470 (5400 Series), 5480 (5400 Series), 5608, 5610, 5611, 5612, 5613, 5709 S DYNA 4, 5709 S DYNA 6, 5709SL, 5710 S DYNA 4, 5710 S DYNA 6, 5710SL, 5711 S DYNA 4, 5711 S DYNA 6, 5711SL, 5712 S DYNA 4, 5712 S DYNA 6, 5712SL, 5713 S DYNA 4, 5713 S DYNA 6, 5713SL, 6445 (6400 Series), 6455 (6400 Series), 6460 (6400 Series), 6465 (6400 Series), 6470 (6400 Series), 6475 (6400 Series), 6480 (6400 Series), 6485 (6400 Series), 6490 (6400 Series), 6495 (6400 Series), 6497 (6400 Series), 6499 (6400 Series), 6612 DYNA 4, 6613 DYNA 4, 6613 DYNA 6, 6614 DYNA 6, 6614 DYNA VT, 6615 DYNA 4, 6615 DYNA 6, 6615 DYNA VT, 6616 DYNA 6, 6616 DYNA VT, 6712 S DYNA 4, 6713 S DYNA 4, 6713 S DYNA 6, 6713 S DYNA VT, 6714 S DYNA 4, 6714 S DYNA 6, 6714 S DYNA VT, 6715 S DYNA 4, 6715 S DYNA 6, 6715 S DYNA VT, 6716 S DYNA 6, 6716 S DYNA VT, 6718 S DYNA 6, 6718 S DYNA VT, 7465 (7400 Series), 7480 (7400 Series), 7485 (7400 Series), 7485 DYNA VT/DYNA STEP, 7490 (7400 Series), 7614 DYNA 4, 7615 DYNA 4, 7615 DYNA 6, 7615 DYNA VT/DYNA STEP, 7616 DYNA 6, 7616 DYNA VT/DYNA STEP, 7618 DYNA 6, 7618 DYNA VT/DYNA STEP, 8450 (8400 Series), 8460 (8400 Series), 8470 (8400 Series), 8480 (8400 Series) |
