Directional Hazard LED, 4 LEDs, Light Colour: Clear
Part Number: S.164689Categories: Electrical Accessories
Part Number: S.164689
Grade: Replacement
Part Details
Directional Hazard LED, 4 LEDs, Light Colour: Clear ECE Rating: Reg 10, Reg 65CE Approved: YesIP Rating: IP67Performance, versatility and style, combined in a compact and sleek design enable installation in alternative locations of the vehicleWith multiple flash patterns, including steady burn and dimmable modesSynchronizablePolycarbonate lens and waterproof housing ensure extended life
Technical Information
| Brand | ECCO |
| Cable length mm | 194 |
| CE Approved | Yes |
| ECE Rating | Reg 10, Reg 65 |
| Fixing | Screw |
| Function | 30 Flash Patterns |
| Housing Material | Polycarbonate |
| Interference EMC EMI CISPR 25 | Not Classified |
| IP Rating | IP67 |
| Lens Colour | Clear |
| Lens Material | Polycarbonate |
| Light Colour | Clear |
| Light source | LED |
| Number of LEDs | 4 LEDs |
| Overall height mm | 35 |
| Overall length mm | 120 |
| Overall width mm | 15 |
| Power Consumption @ 12V | 0.7Amps |
| Related Products | 164688, 164695, 164697, 164699, 164701 |
| RoHS Approved | Yes |
| SAE Approved | Yes |
| Shape | Rectangular |
| Tariff Code | 8512909000 |
| With Noise Suppression | No |
| Working Temperature Degrees Centregrade | -40°C to 65°C |
