Dicsa Trale Hydraulic Hose - 5/16'' 2SN 2 Wire Standard (Cardboard Reel)
Part Number: S.114313Categories: Hydraulics
Part Number: S.114313
Grade: Replacement
Part Details
Dicsa Trale Hydraulic Hose - 5/16'' 2SN 2 Wire Standard (Cardboard Reel) 2SN 2 Wire Standard DIN EN853-2SN-SAE100 R2AT
Technical Information
| Brand | Dicsa Trale |
| Burst pressure bar | 1400 |
| Burst pressure psi | 20300 |
| Construction | 2 Wire |
| Ferrule Part Number | S.112565 |
| Hose inner Ø ins | 5/16 |
| Hose inner Ø mm | 7.9 |
| Hose outer Ø ins | 5/8 |
| Hose outer Ø mm | 16.3 |
| Maximum Working Pressure bar | 350 |
| Maximum Working Pressure psi | 5075.0 |
| Minimum Bend Radius mm | 115 |
| Nominal I.D. | DN08 |
| Pack Type | Cardboard Reel |
| Reference | MS35110550R |
| Related Products | 112565 |
| Roll length M | 50 |
| Specification | 2SN 2 Wire Standard DIN EN853-2SN-SAE100 R2AT |
| Tariff Code | 4009320000 |
| Type | 2SN 2 Wire Standard |
