Dicsa Metric 24° Hose Insert 1'' x M36 x 2 (28L) 135° Swept Swivel With O-Ring
Part Number: S.116758Categories: Hydraulics
Part Number: S.116758
Grade: Replacement
Part Details
Dicsa Metric 24° Hose Insert 1'' x M36 x 2 (28L) 135° Swept Swivel With O-Ring
Technical Information
| Brand | Dicsa |
| C Ø mm | 19 |
| Cone angle | 24° |
| DN Ø ins | 1 |
| DN Ø mm | 25.4 |
| Fitting | 2 Piece Fitting |
| Hex1 mm | 41 |
| Hose inner Ø ins | 1 |
| Hose inner Ø mm | 25.4 |
| L mm | 132 |
| L1 mm | 47 |
| L2 mm | 29.5 |
| Nominal I.D. | DN25 |
| Position | 135° Swept Swivel With O-Ring |
| Reference | 24306362816 |
| Related Products | 112570, 116656 |
| Tariff Code | 7307199000 |
| Thread Male or Female | Female Thread |
| Thread size R1 | M36 x 2 |
| Thread type | Metric |
| Tube Ø mm | 28 |
| Tube Series | 28L |
