Alternator (Sparex) - 14V, 65 Amps for Perkins AD4.203 (4.203 Series)
Part Number: S.359381Categories: Electrical Accessories
Part Number: S.359381
Grade: Replacement
Part Details
Alternator (Sparex) - 14V, 65 Amps Pulley type: Single Groove, Pulley Ø: 90mm
Technical Information
| Amps | 65 |
| B mm | 10.5 |
| Belt pulley width mm | 12.7 |
| Brand | Sparex |
| Connection Type | Ring Terminal |
| Fan Type | External |
| Height mm | 170 |
| Length mm | 190 |
| Mounting Hole mm | 10.5 |
| Number of holes | Two |
| Nut | Hex Nut |
| Pulley Ø mm | 90 |
| Pulley type | Single Groove |
| Shaft Length mm | 38.5 |
| Shaft Type | Hex |
| Supplied with Fan | Yes |
| Tariff Code | 8511500090 |
| Volts | 14V |
| Width mm | 210 |
Manufacturer Part Numbers
| Iskra |
|---|
| IA0692, IA0693 |
| Landini |
| 1895398M91, 3381352M91, 3405390M1, 3581387M1, 3619490M00 |
| Lucas |
| 24088, 24204, LRA220, LRA380, LRA961, LRA964 |
| Massey Ferguson |
| 1699881M91, 1895398M91, 1895398R1, 2541131, 3381352M91, 3405390M1, 3405390R1, 3467043M91, 3467043R91, 3581387M1, 3619490M00, 3933144M91, 908487M1 |
| Renault |
| 6005003157, 6005701123, 7700012969, 7700017041 |
