Alternator (Sparex) - 12V, 120 Amps for McCormick MTX120 (MTX Series)
Part Number: S.68316Categories: Electrical Accessories
Part Number: S.68316
Grade: Replacement
Part Details
Alternator (Sparex) - 12V, 120 Amps Pulley type: PV x 8, Pulley Ø: 55mm
Technical Information
| Amps | 120 |
| B mm | 10.2 |
| Brand | Sparex |
| Connection Type | Connector |
| Fan Type | External |
| Height mm | 250 |
| Length mm | 180 |
| Mounting Hole mm | 10.2 |
| Number of holes | Two |
| Nut | Hex Nut |
| Pulley Ø mm | 55 |
| Pulley type | PV x 8 |
| Shaft Length mm | 34 |
| Shaft Type | Splined |
| Supplied with Fan | Yes |
| Tariff Code | 8511500090 |
| Volts | 12V |
| Width mm | 190 |
Manufacturer Part Numbers
| Bosch |
|---|
| 0124325052, 0124515044, 0124515113, 0124515120 |
| Case IH |
| 706315A1 |
| Ford New Holland |
| 47129299 |
| Landini |
| 706315A1, 710627A1 |
