90° Coupling with Hose End - Female 4'' (108mm) x4'' (102mm) (Galvanised)
Part Number: S.136641Categories: Muck Spreader
Part Number: S.136641
Grade: Replacement
Part Details
90° Coupling with Hose End - Female 4'' (108mm) x4'' (102mm) (Galvanised) Coupler type: Perrot FittingLength: 605mm A: 164mmB: 152mmC: 605mmD: 473mmSupplied with Gasket Ring and Clamp RingFitted with locking pin & Chain to stop clamp handle from accidentally opening
Technical Information
| Ø ins | 4 |
| Ø mm | 108 |
| A mm | 164 |
| B mm | 152 |
| Brand | Sparex |
| C mm | 605 |
| Coupler type | Perrot Fitting |
| D mm | 473 |
| Finish | Galvanised |
| Hose end size mm | 102 |
| Length mm | 605 |
| Male Female | Female |
| Notes | Fitted with locking pin & Chain to stop clamp handle from accidentally opening |
| Supplied with | Gasket Ring and Clamp Ring |
| Tariff Code | 7307199000 |
